20 A White Tamper Resistant Single Receptacle

UPC
032664668395
Online Sku
1003867
Model Number
TR1877W-SP-L
$0.00
$9.99
  • Ready to Deliver
  • 5 Available for pick up at
2-Pole 3-Wire Tamper-resistant single receptacle has voltage rating of 125 VAC and current rating of 20 Amps. Receptacle with side wired terminal connection, accommodates 10 AWG wire. The white commercial grade receptacle features high impact-resistant thermoplastic face and back body. It withstands dielectric strength of 2000 Volts. The double wipe ground contacts enable long-term ground retention. The 3/100 in thick triple wipe brass contact enables excellent plug blade retention. It has 0.1016 cm thick galvanized steel strap. Receptacle withstands temperature rating of -20 to 70 deg C. Receptacle is UL/cULus listed and meets NOM/ANSI standards.
  • Tamper-resistant receptacles provide compliance with 2011 NEC® Article 406.12
  • Feature "TR" designation for easy visual identification
  • High impact-resistant thermoplastic face and back body effectively eliminates breakage
  • Double-wipe ground contacts ensure long-term ground retention
  • Side wire terminals accept solid wire of size up to #10 AWG
  • Standards: cULus Listed to UL498, NOM/ANSI certified
Manufacturer's Warranty Lifetime On Manufacturing Defect
Colour White
Temperature Rating (C) -20 to 70
GFCI No
Voltage Rating 125 V CA
Amperage Rating 20 Amp
Terminal Connection Side Wire
Number of Poles 2
Durability Commercial
Number of Wires 3
NEMA Configuration NEMA 5-20R
Dielectric Strength 2000 Volt
Environmental Conditions V2 Flammability Rated Per UL94
Style Unique

Overview

2-Pole 3-Wire Tamper-resistant single receptacle has voltage rating of 125 VAC and current rating of 20 Amps. Receptacle with side wired terminal connection, accommodates 10 AWG wire. The white commercial grade receptacle features high impact-resistant thermoplastic face and back body. It withstands dielectric strength of 2000 Volts. The double wipe ground contacts enable long-term ground retention. The 3/100 in thick triple wipe brass contact enables excellent plug blade retention. It has 0.1016 cm thick galvanized steel strap. Receptacle withstands temperature rating of -20 to 70 deg C. Receptacle is UL/cULus listed and meets NOM/ANSI standards.
  • Tamper-resistant receptacles provide compliance with 2011 NEC® Article 406.12
  • Feature "TR" designation for easy visual identification
  • High impact-resistant thermoplastic face and back body effectively eliminates breakage
  • Double-wipe ground contacts ensure long-term ground retention
  • Side wire terminals accept solid wire of size up to #10 AWG
  • Standards: cULus Listed to UL498, NOM/ANSI certified

Specifications

Manufacturer's Warranty Lifetime On Manufacturing Defect
Colour White
Temperature Rating (C) -20 to 70
GFCI No
Voltage Rating 125 V CA
Amperage Rating 20 Amp
Terminal Connection Side Wire
Number of Poles 2
Durability Commercial
Number of Wires 3
NEMA Configuration NEMA 5-20R
Dielectric Strength 2000 Volt
Environmental Conditions V2 Flammability Rated Per UL94
Style Unique
